Writing 48kHz audio DSP kernels in Field language

Most modern digital audio workstations treat audio synthesis as a black box: you write a C++ plugin, compile a VST3 or AU bundle with JUCE or Dplug, restart your host, and attach a debugger.

In Infinite, you can write audio DSP at the sample level directly inside the canvas using Field language. Your code runs on the audio thread once per sample (48,000 times per second), compiled to a register machine that executes with zero memory allocations.

How the Sample Register Machine Works

When you place a Field Synth (Synths Field Synth) or Field Effect (AudioEffects Field Effect) node, Infinite compiles the kernel expression to a compact bytecode representation that evaluates on register cells.

Built-in Variables Available on the Audio Thread:

• sr: Audio sample rate in Hz (typically 48000.0).
• in: Incoming audio sample value ([-1.0, 1.0]) in Field Effect.
• out: Output audio sample to write.
• freq: Note frequency in Hz (voice pitch in Field Synth).
• gate: 1.0 while a MIDI note is held down, 0.0 when released.
• noteVel: Key velocity ([0.0, 1.0]).
• state: Declares per-voice persistent memory preserved across samples.
• param: Exposes a modulatable float knob on the node body with min/max bounds.

A 1-Pole Lowpass Filter Kernel

Here is a classic 1-pole lowpass filter written in 4 lines:

param float cutoff = 0.25 [0.01, 0.99]
state float z = 0
z += (in - z) * cutoff
out = z

Because state float z = 0 allocates a persistent cell in the voice register, z retains its previous sample value, creating an analog RC filter response.

Shipped Moog 4-Pole Ladder Filter

For aggressive saturation and self-oscillation, Infinite ships with a 4-pole cascaded non-linear filter:

param float cutoff = 2200.0 [80.0, 14000.0]
param float res = 0.70 [0.0, 0.98]
param float drive = 1.50 [1.0, 4.0]
param float mix = 1.0 [0.0, 1.0]
state float s1 = 0
state float s2 = 0
state float s3 = 0
state float s4 = 0

f = clamp((cutoff / sr) * 2.2, 0.005, 0.42)
feedback = (s4 * res * 3.6) / (1.0 + abs(s4) * 0.8)
u = (in * drive) - feedback
sat = u / (1.0 + abs(u) * 0.3)

s1 = s1 + f * (sat - s1)
s2 = s2 + f * (s1 - s2)
s3 = s3 + f * (s2 - s3)
s4 = s4 + f * (s3 - s4)

wet = s4
out = in * (1.0 - mix) + wet * mix

Notice the dry/wet mix pattern at the end: every Field audio effect ends with out = in * (1.0 - mix) + wet * mix, giving you instant parallel processing.

Real-Time Mod Matrix Integration

Unlike fixed DSP plugins, a Field Effect node can publish meter readings back to the visual and modulation canvas using reduce.rms:

param float boost = 1.5 [0.5, 4.0]
output frame float bass = reduce.rms(in, 20.0, 200.0)
out = in * boost

The bass scalar automatically becomes a second output pin on the node. You can run a cable from that pin directly into a 3D geometry deformer, a light intensity slider, or a GLSL shader.

Testing and Verifying Headlessly

You can test Field kernels without opening the GUI using Infinite's CLI or Python SDK:

import infinite

# Synthesize a custom per-sample subtractive saw voice
infinite.field_synth("""
state float phase = 0
phase = (phase + freq / sr) % 1.0
out = (phase * 2.0 - 1.0) * 0.3 * gate
""", out_wav="saw.wav", duration=3)

The CLI synthesizes the audio, measures integrated LUFS, checks for clipped frames, and writes the output file with zero GUI dependencies.
