Audio effects node
Spec Blur
A streaming phase vocoder that smears the spectrum over time. Sharp hits dissolve into a harmonic cloud, with tilt, phase diffusion and freeze controls. It adds 42.7 ms of delay, and its mix defaults to fully wet.
What it does
Spec Blur is an audio effect: it changes the sound that flows through it. It takes audio in and gives audio out.
Try it
Freeze a held chord and let it hang as a pad while you play over the top.
WavetableSpec BlurReverbAudio Out
Inputs and outputs
Inputs
- audio audio
Outputs
- audio out
Controls
Every control with a range can be driven by a modulator, a note, an audio level or a sketch.
| Control | Range or options | Default |
|---|---|---|
| mix | 0 to 1 | 1 |
| blur | 10 to 5000 | 300 |
| tilt | -1 to 1 | 0 |
| diffuse | 0 to 1 | 0.25 |
Example patch
This patch wires Spec Blur to what it needs and shows the result. Download it, then use File, Open in Infinite, or read it here: it is plain text.
infinite-patch 1
rev 2
# Spec Blur: a starting patch for the Spec Blur node
node 1 AudioEffects Spec Blur
id node
pos 520 300
end
node 2 Synths Oscillator
id in0
pos 0 300
end
node 3 Utility Audio Out
id speakers
pos 1080 300
end
aud node 0 in0
aud speakers 0 node
