Intersect
Intersect is a 3D node: it builds, changes or lights geometry that Render 3D turns into a picture. It takes 3D shape in and gives 3D shape out. Its controls include mode, material from input.
What it does
Intersect is a 3D node: it builds, changes or lights geometry that Render 3D turns into a picture. It takes 3D shape in and gives 3D shape out.
Inputs and outputs
Inputs
- 3D shape geo A
- 3D shape geo B
- 3D shape geo C
- 3D shape geo D
Outputs
- 3D shape out
Controls
Every control with a range can be driven by a modulator, a note, an audio level or a sketch.
| Control | Range or options | Default |
|---|---|---|
| mode | Merge, Union, Intersect, Difference | 2 |
| material from input | 0 to 3 | 0 |
Example patch
This patch wires Intersect to what it needs and shows the result. Download it, then use File, Open in Infinite, or read it here: it is plain text.
infinite-patch 1
rev 2
# Intersect: a starting patch for the Intersect node
node 1 3D Intersect
id node
pos 520 300
end
node 2 3D Cube
id in0
pos 0 220
end
node 3 3D Cube
id in1
pos 0 510
end
node 4 3D Cube
id in2
pos 0 800
end
node 5 3D Cube
id in3
pos 0 1090
end
node 6 3D Render 3D
id view
pos 1080 300
end
node 7 Utility Output
id out
pos 1640 300
end
geo node 0 in0
geo node 1 in1
geo node 2 in2
geo node 3 in3
geo view 0 node
cable out 0 view
